Best Quality Silent Generator Engine 450KVA Generator Set With USA QSZ13-G5 360KW Diesel Generator Price
Ai power USA Cummins generator set adopts USA Cummins engine as the power source. it’s a global power leader who is devoted to the engine R&D and manufacturer since 1919 in Columbus, now it has become the largest engine manufacturer in the world providing more than 160 countries sales and aftersales service. Ai Power Cummins series generator has adopted Cummins engine include 4B, 6B, 6C, 6L, NTA, MTA, KTA series etc.
Product characteristics:
1. Our cooperate with famous diesel engine -Powered by famous Cummins engines.
2. Equipped with famous Brushless alternator - Optional Stamford, Leroy Somer, Marathon, Meccalte.
3. Equipped with 50°C radiator with fan, enough engine cooling system guarantee long time working
4. Equipped with advanced generator set control system, ATS system, remote control system, parallel operation system, optional control model, Deep sea, Smartgen, ComAp,
5. Generator set use High-quality steel are thickness canopy -- 2MM to 6MM
6. Generator equipped with 24V DC battery with charger, battery connects wire.
7. New design of turn-back type for air inflow & air outlet which can reduce the noise and improve engine efficiency.
8. Beautiful & practicably design, Bottom hole for forklift, Water outlet & oil outlet for easy maintenance
Generator Specifications:
| GENERAL ENGINE DATA | |
| Engine manufacturer | Chongqing Cummins Engine Co., Ltd. |
| Engine brand | Cummins |
| Engine model | NTAA855-G7A |
| Engine speed (rpm) | 1500 |
| Engine output(kW) | |
| | Standby power rating | 407 |
| | Prime power rating | N/A |
| Type | 4-Cycle, In line, 6 Cylinder |
| Aspiration | Turbocharged and air to air cooled |
| Bore * Stroke (mm) | 140 * 152 |
| Displacment (litre) | 14 |
| Compression Ratio | 14.0:1 |
| |
| FUEL SYSTEM | |
| Type Injection System | Direct Injection Cummins PT |
| Fuel Consumption (litre/hour) | |
| | 100% output power | 89.2 |
| | 75% output power | 67.8 |
| | 50% output power | 47.5 |
| | 25% output power | 26.4 |
| |
| EXHAUST SYSTEM | |
| Maximum Back Pressure (kPa) | 10 |
| Exhaust Gas Temperature (overload/prime power) (°C) | 473 / N/A |
| Exhaust Gas Flow(overload/prime power) (liter/s) | 1240 / N/A |
| |
| AIR INDUCTION SYSTEM | |
| Maximum Intake Air Restriction (in. H2O) | |
| | with Dirty Filter Element | 25 |
| | with Clean Filter Element | 15 |
| Intake Air Flow (overload/prime power) (liter/s) | 549 / N/A |
| |
| COOLING SYSTEM | |
| Coolant Capacity — Engine Only (liter) | 20.8 |
| Standard Thermostat Modulating Range | 82-94 |
| Maximum Coolant Temperature (°C) | 96 |
| Minimum Allowable Pressure Cap -PSI | 7 |
| Maxi. Top Tank Temp. (°C) | 100 |
| |
| LUBRICATION SYSTEM | |
| Oil Pressure (kPa) | |
| | Idle Speed | 103 |
| | Governed Speed | 241-345 |
| Maximum Oil Temperature (°C) | 121 |
| Total System Capacity (with LF9009 Combine Filter) (liter) | 38.6 |
| |
| ELECTRICAL SYSTEM | |
| Cranking Motor (Heavy Duty, Positive Engagement) (volt) | 24 |
| Battery Charging System, Negative Ground (ampere) | 35 |
Detection and protection function
Ai Power Company
Xiamen Ai Power Technology Co.,Ltd, which is located in the beautiful tourism city of Xiamen city, Fujian Province, It is dedicated to becoming a comprehensive company for intelligent power and green energy supply. Our company aim to create a better life for the world by supplying better power solutions. Continually improving products’ quality, friendly-use and durability is our long-term mission. We will make all the efforts to walk a long way to reach customers’ greatest satisfaction.
-
Over / under speed, Low Oil Pressure, High Water Temperature, under Battery Volt, Low water level,Three failed to start alarm
-
Over / under voltage,Over current,Over / under frequency, Over Power, Short circuit
Optional features
-
RS485 (DSE7320)RS485(DSE7320)
-
Fuel level display and low-alarm
-
Water level low-alarm
-
Water Pre- heating in low temperature
-
ATS
-
Automatic parallel (DSE6120 / DSE7320)
-
Other self-definition functions
-
big power 1mva silenced diesel generator set price
FAQ
1. What is your warranty period?
A:Our warranty period is 1 year or 1000 running hours, whichever comes first (Except the damageable spare parts of genset caused by incorrect man-made operation).
2. Does your generator have global warranty?
A:Yes. Gensets powered by USA famous engine, with UK famous engine, Volvo, Iveco have the global warranty service. And the alternators Stamford, Leroysomer, Meccalte, Marathon also have the global warranty service.
3. What is your payment terms?
A:T/T 30% advance payment, the balance 70% shall be paid before shipment, L/C at sight.
4. Can the generators be customized?
A: Yes. Our generators can be customized depending on customer's detailed requirements. We can supply generators for rental business, home use, industrial projects, army projects, power station, etc. The generators we supply is suitable for indoor and outdoor use, lower and high temperature environment.
5. Can you use our logo?
A: Yes. For mass orders, we can use customer's logo instead of ours.
